15. Engine Removal, Inspection & Installation
z Remove spring ①
z Remove spring seat .②
z Remove guide pin and spacer.
z Remove secondary sliding sheave ③
O-ring and Oil Seal
Check the O-ring and oil seal for wear and damage. O-ring oil seal
Wear and Damage: → Replace
z Remove Oil Seal
15-33
