15. Engine Removal, Inspection & Installation
Inspection
z Check main shaft gear and sprocket surface for any
damage or over wear.
Damage or over wear: → Replace
z Check reverse gear chain for any damage or over
wear.
Damage or over wear: → Replace
z Disassemble driven shaft as illustrated.
z Check each gear surface for any damage or over
wear.
z Check bearing and collar for any wear or damage..
Damage or over wear: → Replace
15-38
