CG Emotron VFX48 Series User Manual

CG Drives & Automation, 01-5326-01r5 Mounting 19
Fig. 18 Emotron VFX Model 48-090 to 175 (Frame size E).
Fig. 19 Cable interface for mains, motor, DC+/DC-, brake
resistor and communication, Emotron VFX Model 48-
090 to 175 (Frame size E).
Fig. 20 Emotron VFX Model 48-210 to 295 (Frame size F),
Emotron VFX Model 69-82 to 200 (Frame size F69).
Fig. 21 Cable interface for mains, motor, DC+/DC-, brake
resistor and communication, Emotron VFX Model 48-
210 to 295 (Frame size F), Emotron VFX Model 69-
082 to 200 (Frame size F69).
CD
F
H
A
B
E
G
ø16 mm(x3)
(0.63 in)
ø9 mm(x6)
(0.35 in)
56/60 kg
(124/132 lb)
Cable glands M20
Cable flexible leadthrough
Ø17-42 /M50
Ø11-32 /M40
(0.67 - 1.65in)
(0.43 - 1.2 in)
Cable flexible leadthrough
C
D
F
H
A
B
E
G
ø9 mm(x6)
(0.35 in)
ø16 mm(x3)
(0.63 in)
74 kg
163 lb)
Cable glands M20
Cable flexible leadthrough
Ø23-55 /M63
Ø17-42 /M50
(0.91 - 2.1 in)
(0.67 - 1.65in)
Cable flexible leadthrough
Table 10 Dimensions IP54 connected to Fig. 18 and Fig. 20.
Frame
size
Emotron VFX
model
Dimension in mm (in)
A B C D E F
G
(depth)
H
E 090 - 175
925
(36.4)
950
(37.4)
240
(9.5)
22.5
(0.88)
10 (0.39)
284.5
(11.2)
314
(12.4)
120
F 210 - 295
925
(36.4)
950
(37.4)
300
(11.8)
22.5
(0.88)
10 (0.39)
344.5
(13.6)
314
(12.4)
150
F69 082 - 200
1065
(41.9)
1090
(42.9)
