CG Emotron VFX48 Series User Manual

CG Drives & Automation 01-5326-01r5 Technical Data 237
Emotron VFX 2.0 - IP54 version (Model 48-300 and up also available as IP20)
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 53 Typical motor power at mains voltage 230 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame
size
(Number
of
PEBB´s **)
IP
class
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
Power
@230V
[kW]
Power
@230V
[HP]
Rated
current
[A]
48-003-54 3.8 0.37 0.5 2.5 0.37 0.5 2.0
B
IP 54
wall
mounted
48-004-54 6.0 0.75 1 4.0 0.55 0.75 3.2
48-006-54 9.0 1.1 1.5 6.0 0.75 1 4.8
48-008-54 11.3 1.5 2 7.5 1.1 1.5 6.0
48-010-54 14.3 2.2 3 9.5 1.5 2 7.6
48-013-54 19.5 2.2 3 13.0 2.2 3 10.4
48-018-54 27.0 4 5 18.0 3 3 14.4
48-026-54 39 5.5 7.5 26 4 5 21
C
48-031-54 46 7.5 10 31 5.5 7.5 25
48-037-54 55 7.5 10 37 7.5 10 29.6
48-046-54 69 11 15 46 7.5 10 37
48-061-54 92 15 20 61 11 15 49
D
48-074-54 111 18.5 25 74 15 20 59
48-090-54 108 22 30 90 18.5 25 72
E
48-109-54 131 30 40 109 22 30 87
48-146-54 175 37 50 146 30 40 117
48-175-54 210 45 60 175 37 50 140
48-210-54 252 55 75 210 45 60 168
F
48-228-54 300 55 75 228 55 60 182
48-250-54 300 75 100 250 55 75 200
48-295-54 354 90 125 295 75 100 236
48-365-54 438 110 150 365 90 125 292 FA
48-300-IP 360 90 125 300 75 100 240
G(2)
IP 20
module
or IP54
cabinet
48-375-IP 450 110 150 375 90 125 300
48-430-IP 516 110 150 430 110 125 344
H(2)
48-500-IP 600 160 200 500 110 150 400
48-600-IP 720 200 250 600 132 200 480
I(3)48-650-IP 780 200 250 650 160 200 520
48-750-IP 900 220 300 750 200 250 600
48-860-IP 1032 250 350 860 220 300 688
J(4)
48-1K0-IP 1200 300 400 1000 250 350 800
48-1K15-IP 1380 355 450 1150 250 400 920
KA(5)
48-1K25-IP 1500 400 500 1250 315 400 1000
48-1K35-IP 1620 400 550 1350 355 450 1080
K(6)
48-1K5-IP 1800 450 600 1500 400 500 1200
48-1K75-IP 2100 560 750 1750 450 600 1400 L(7)
48-2K0-IP 2400 630 800 2000 500 650 1600 M(8)
48-2K25-IP 2700 710 900 2250 560 750 1800 N(9)
48-2K5-IP 3000 800 1000 2500 630 800 2000 O(10)
Larger sizes available on request
