238 Technical Data CG Drives & Automation 01-5326-01r5
* Available during limited time and as long as allowed by drive temperature.
** PEBB= Power Electronic Building Block (power module).
Table 54 Typical motor power at mains voltage 400 V. AC drive main voltage range 230 - 480 V.
Model VFX
Max.
output
current
[A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
(Number of
PEBB´s)**
IP
class
Power
@400V
[kW]
Rated
current
[A]
Power
@400V
[kW]
Rated
current
[A]
48-003-54 3.8 0.75 2.5 0.55 2.0
B
IP 54
wall
mounted
48-004-54 6.0 1.5 4.0 1.1 3.2
48-006-54 9.0 2.2 6.0 1.5 4.8
48-008-54 11.3 3 7.5 2.2 6.0
48-010-54 14.3 4 9.5 3 7.6
48-013-54 19.5 5.5 13.0 4 10.4
48-018-54 27.0 7.5 18.0 5.5 14.4
48-026-54 39 11 26 7.5 21
C
48-031-54 46 15 31 11 25
48-037-54 55 18.5 37 15 29.6
48-046-54 69 22 46 18.5 37
48-061-54 92 30 61 22 49
D
48-074-54 111 37 74 30 59
48-090-54 108 45 90 37 72
E
48-109-54 131 55 109 45 87
48-146-54 175 75 146 55 117
48-175-54 210 90 175 75 140
48-210-54 252 110 210 90 168
F
48-228-54 300 110 228 90 182
48-250-54 300 132 250 110 200
48-295-54 354 160 295 132 236
48-365-54 438 200 365 160 292 FA
48-300-IP 360 160 300 132 240
G(2)
IP 20
module
or IP54
cabinet
48-375-IP 450 200 375 160 300
48-430-IP 516 220 430 200 344
H(2)
48-500-IP 600 250 500 220 400
48-600-IP 720 315 600 250 480
I(3)48-650-IP 780 355 650 315 520
48-750-IP 900 400 750 355 600
48-860-IP 1032 450 860 400 688
J(4)
48-1K0-IP 1200 560 1000 450 800
48-1K15-IP 1380 630 1150 500 920
KA(5)
48-1K25-IP 1500 710 1250 560 1000
48-1K35-IP 1620 710 1350 600 1080
K(6)
48-1K5-IP 1800 800 1500 630 1200
48-1K75-IP 2100 900 1750 800 1400 L(7)
48-2K0-IP 2400 1120 2000 900 1600 M(8)
48-2K25-IP 2700 1250 2250 1000 1800 N(9)
48-2K5-IP 3000 1400 2500 1120 2000 O(10)
Larger sizes available on request
