CG Emotron VFX48 Series User Manual

CG Drives & Automation 01-5326-01r5 Technical Data 251
Note: For IP54 models 48/52-003 to -074 and 69-002 to -058 cable glands are optional.
* IP20/21 models are equipped with cable clamps instead of glands.
For data on cable connection ranges, see section 3.4.3, page 39
69-250-IP 216 250
-- --
69-300-IP 260 300
69-375-IP 324 355
69-400-IP 346 400
69-430-IP 372 400
69-500-IP 432 500
69-595-IP 516 630
69-650-IP 562 630
69-720-IP 648 710
69-800-IP 692 800
69-905-IP 795 900
69-995-IP 864 1000
-- --
69-1K2-IP 1037 1250
69-1K4-IP 1213 1500
69-1K6-IP 1382 1600
69-1K8-IP 1555 2 x 900
69-2K0-IP 1732 2 x 900
69-2K2-IP 1900 2 x 1000
69-2K4-IP 2074 2 x 1250
69-2K6-IP 2246 2 x 1250
69-2K8-IP 2419 2 x 1500
69-3K0-IP 2592 2 x 1500
Table 66 Fuses, cable cross-sections and glands for 690V models
Model VFX
Nominal input
current
[A]
Maximum
value fuse
[A]
Cable glands (clamping range ) *
mains / motor Brake
