CG Emotron VFX48 Series User Manual

250 Technical Data CG Drives & Automation 01-5326-01r5
Table 66 Fuses, cable cross-sections and glands for 690V models
Model VFX
Nominal input
current
[A]
Maximum
value fuse
[A]
Cable glands (clamping range ) *
mains / motor Brake
69-002-54 1.6 4 M32 (8 - 17 / 9 - 17 mm) M25 (9 - 17 mm)
69-002-20 1.6 4
8 - 12 mm (0.32 - 0.47 in)
12 - 16 mm (0.47 - 0.63 in)
69-003-54 2.3 4 M32 (8 - 17 / 9 - 17 mm) M25 (9 - 17 mm)
69-003-20 2.3 4
8 - 12 mm (0.32 - 0.47 in)
12 - 16 mm (0.47 - 0.63 in)
69-004-54 3.1 4 M32 (8 - 17 / 9 - 17 mm) M25 (9 - 17 mm)
69-004-20 3.1 4
8 - 12 mm (0.32-0.47 in)
12 - 16 mm (0.47-0.63 in)
69-006-54 4.7 6 M32 (8 - 17 / 9 - 17 mm) M25 (9 - 17 mm)
69-006-20 4.7 6
8 - 12 mm (0.32 - 0.47 in)
12 - 16 mm (0.47 - 0.63 in)
69-008-54 6.3 10 M32 (8-17 / 9 - 17 mm) M25 (9 - 17 mm)
69-008-20 6.3 10
8 - 12 mm (0.32 - 0.47 in)
12 - 16 mm (0.47 - 0.63 in)
69-010-54 7.8 10 M32 (8-17 / 9 - 17 mm) M25 (9 - 17 mm)
69-010-20 7.8 10
8 - 12 mm (0.32 - 0.47 in)
12 - 16 mm (0.47 - 0.63 in)
69-013-54 10.4 16 M32 (9 - 21 /11 - 21 mm) M25 (9 - 17 mm)
69-013-20 10.4 16
12 - 16 mm (0.47 - 0.63 in)
16 - 22 mm (0.63 - 0.87 in)
69-018-54 15.3 20 M32 (9 - 21 / 11 - 21 mm) M25 (9 - 17 mm)
69-018-20 15.3 20
12 - 16 mm (0.47 - 0.63 in)
16 - 22 mm (0.63 - 0.87 in)
69-021-54 17.8 25 M32 (9 - 21 / 11 - 21 mm) M25 (9 - 17 mm)
69-021-20 17.8 25
12 - 16 mm (0.47 - 0.63 in)
16 - 22 mm (0.63 - 0.87 in)
69-025-54 21.2 25 M32 (9-21 / 11-21 mm) M25 (9 - 17 mm)
69-025-20 21.2 25
12 - 16 mm (0.47 - 0.63 in)
16 - 22 mm (0.63 - 0.87 in)
69-033-54 28 35 M50 (19 - 28 / 16 - 28 mm) M40 (16 - 28 mm)
69-033-20 28 35
16 - 22 mm (0.63 - 0.87 in)
22 - 28 mm (0.87 - 1.1 in)
69-042-54 36 50
M50 (19 - 28 / 16-28 mm) M40 (16 - 28 mm)
69-042-20 36 50
16 - 22 mm (0.63 - 0.87 in)
22 - 28 mm (0.87 - 1.1 in)
69-050-54 43 63
M50 (19 - 28 / 16 - 28 mm) M40 (16 - 28 mm)
69-050-20 43 63
16 - 22 mm (0.63 - 0.87 in)
22 - 28 mm (0.87 - 1.1 in)
69-058-54 49 63
M50 (19 - 28 / 16 - 28 mm) M40 (16 - 28 mm)
69-058-20 49 63
16 - 22 mm (0.63 - 0.87 in)
22 - 28 mm (0.87 - 1.1 in)
69-082-54 72 100
(Ø23-55 mm (0.9 - 2.16 in)) Cable flexible leadthrough or M63 opening.
(Ø17-42 mm (0.67 - 1.65 in)) Cable flexible leadthrough or M50 opening.
69-090-54 78 100
69-109-54 94 100
69-146-54 126 160
69-175-54 152 160
69-200-54 173 200
