GAIN Shortcut screen
(1) Shortcut title (Parameter being adjusted, for other Shortcuts, title changes accordingly)
(2) Arrow referring to the UP button [N]. The item below indicates the next value (Up direction)
(3) Next Parameter Value if UP button [N] is pushed (parameter up)
(4) Current Parameter Value
(5) Next Parameter Value if DOWN button [O] is pushed (parameter down)
(6) Arrow referring to the DOWN button [O]. The item below indicates the previous value (down direction)
The last Shortcut (SETUP) is always the same and cannot be removed or altered. It gives access the Menu mode and the detailed
setup of the unit.
DETAILED SETUP Shortcut screen
