4.2 Configuration
The PMOLED display and the LED behavior of the X1 are customizable through two push-buttons located on the control plate at the
back of the unit. Each button has two different functions: a main function and an alternate function.
• The main function is called if the button is pushed while the X1 is in standby or on (i.e. powering a CH unit).
• The alternate function is called if the button is kept pushed while X1's main power switch is flipped from OFF to ON.
Function Button Description
Main 1 Setting selection (scroll across all settings, displaying their value)
2 Setting editing (scroll across all possible value of a particular setting)
Alternate 1 Self-test (check that the X1 is working well, displays a report of all tests)
2 Firmware update (start firmware update when a USB key with valid f/w is plugged)
Control board push-buttons description
The table below lists all X1 settings and available values for each one:
SETTING POSSIBLE VALUES REMARKS
DISPLAY BRIGHTNESS 20%
40%
…
100%
Display brightness during the few seconds following a status modification
LED ON/OFF On
Off
Front LED state when the X1 is ON (i.e. powering at least one CH unit)
DISPLAY MODE Status
Off
What to display when the X1 is left idle for several seconds.
INFORMATION Firmware version
Slot left
Slot Right
Displays software and hardware related information about the X1
X1 settings
18 X1 User Manual Rev 2.1
