CH X1 - 7 Specifications

7 Specifications
General
CH Precision compatible devices (so far) C1, D1, L1and P1
User control Automatic on/standby functions remotely operated from connected device
2 push-buttons at the rear of the unit for configuration
Display 256 x 64 pixels white PMOLED
Power supply Selectable 100V, 115V or 230V AC, 47Hz to 63Hz
Power consumption (Standby mode) < 1W
Power consumption (Normal operation) 40W/80W typical (1/2 devices powered), 400W max
Operating conditions Temperature: +5C to +35C, humidity: 5% to 85% (no condensation)
Dimensions (L x D x H) 440mm x 440mm x 120mm (main body)
Weight 25kg
Software update USB port for firmware update
Output voltages
Analog supplies +/-19V DC
+/-8V DC
+11V DC
Digital supplies +3.4V DC
+5.5V DC
+/-8V DC
+12V DC
Protections
Analog supplies Over-voltage, under-voltage and over-current monitoring
Digital supplies Over-voltage, under-voltage and over-current monitoring
Connections
Back panel 19-poles M23 connector compatible with C1, D1, L1and P1external PSU
connector
Cable 2 meter cable with 19-poles M23 connectors (male & female)
Design and Specifications are subject to change without notice. Weight and dimensions are approximate
Illustrations are informative only and may differ from the actual production model
Enclosure designed by Mana Ishoni
