26
EXHAUST
AIR INTAKE
AIR INTAKE
AIR INTAKE MUST NOT BE
FITTED ABOVE THE EXHAUST
NO
TE
: DRA
WINGS
ARE INDICATIVE OF FLUEING OPTIONS ONLY
.
TYPE 1
TYPE 5
TYPE 4
TYPE 3
TYPE 2
Fig. 30
12.4 Fitting the twin pipe flue (Ø80/80) (continued)
