Approximate refill capacities
Compartment or
system
Liter (gal)
Engine coolant system AGCO® Antifreeze and coolant or equivalent that meets
the following requirements. 50/50 Water and Ethylene/
propylene- glycol without stop leak additive, ASTM
D3306 - See Engine operation and maintenance manual
40 liter (10.6 gal)
Diesel fuel Meets EN590-2009 or ASTM D975 Grade No. 1-D S15
B5 Blend - See Engine operation and maintenance
manual
Fuel tank RH fender 177.5 liter (46.9 gal)
Fuel tank LH fender 173 liter (45.7 gal)
Fuel tank Main 306.6 liter (81.0 gal)
Fuel tank extra with
standard gauge
[1]
113.5 liter (30.0 gal)
Fuel tank extra 284 liter (75 gal)
Engine crankcase and
filter
AGCO® Multiguard® SAE15W-40 API grade CJ-4 or
ACEA E9
34.8 liter (9.2 gal)
Windscreen Washer
Reservoir
HFC-F-134A 4.0 liter (1.1 gal)
Refrigerant R134A 1.46 kg (3.2 lb)
Hydraulic System
AGCO® Permatran®
821XL
Standard gauge 227 liter (60 gal)
Wide gauge 235 liter (62 gal)
Ultra wide gauge 265 liter (70 gal)
Front idler hub AGCO® Synthetic Final Drive and Axle Oil SAE 50 0.49 liter (0.13 gal)
Midwheel hub AGCO® Synthetic Final Drive and Axle Oil SAE 50 0.15 liter (0.04 gal)
Drive wheel hub AGCO® Synthetic Final Drive and Axle Oil SAE 50 1.40 liter (0.37 gal)
Grease Fittings AGCO® Grease Hi Temperature Moly-Lithium Base As necessary
[1]
Not available with 34" belts and overall width with 30" belts is 3.00 meters
Approximate refill capacities
Compartment or
system
Liter (gal)
Engine coolant system AGCO® Antifreeze and coolant or equivalent that meets
the following requirements. 50/50 Water and Ethylene/
propylene- glycol without stop leak additive, ASTM
D3306 - See Engine operation and maintenance manual
40 liter (10.6 gal)
Diesel fuel Meets EN590-2009 or ASTM D975 Grade No. 1-D S15
B5 Blend - See Engine operation and maintenance
manual
Fuel tank RH fender 177.5 liter (46.9 gal)
Fuel tank LH fender 173 liter (45.7 gal)
Fuel tank Main 306.6 liter (81.0 gal)
4
1. General
1-22 Rubber Track Tractor
79036614D
