Challenger MT755E Workshop Service Manual

Title Description
Steering system Machine has a dierential steering system. Steering
system controls dierence in speed between two
belts during turns.
Steering system consists of the following
components: three planet gear sets, A bidirectional
hydraulic steering motor.
Three point hitch 3-Point linkage is electronically controlled. 3-Point
linkage will accept category III, and category IVN
implements.
Lift capacity for 3-point linkage 7260 kg (16 000 lb).
Lift capacity for the ultra wide machines are limited
to 5443 kg (12 000 lb). Transporting a hitch mounted
load at speeds above 17.7 km/h (11 mph), can result
in structural damage, and may void warranty due to
overload conditions. Top speed on the ultra wide
machines are limited to gear 15F. Gear 16F is locked
out automatically when machine is configured as an
ultrawide in CAT ET.
Power Take O PTO shaft is a 44.5 mm (1.75 in) 20 tooth spline,
and the PTO shaft is a fixed shaft.
Fuel tank Additional tank - 282.0 liter (74.5 gal).
Standard fuel tank capacity 657.1 liter (173.6 gal).
Additional tank is standard on wide and ultra wide
gauge machines.
Debris deflector compatability No fuel tank - <2032 mm (80 in) gauge setting - not
compatible with debris deflectors
With additional tank <2489.2 mm (98 in) gauge
setting - not compatible with debris deflectors
Gauge- belt compatibility with auxilary fuel tank Compatibility with 282.0 liter (74.5 gal) additional
side fuel tank
2032 mm(80 in) to 2057.4 mm (81 in) gauge setting
- compatible with 355.6 mm (14 in) belts
2082.8 mm (82 in) to 2108.2 mm (83 in) gauge
setting - compatible with 355.6 mm (14 in), 406.4
mm (16 in) belts
2133.6 mm (84 in) to 2209.8 mm (87 in) gauge
setting - compatible with 355.6 mm (14 in), 406.4
mm (16 in), 457.2 mm (18 in) belts
2235.2 mm (88 in) to 2413 mm (95 in)gauge setting
- compatible with 355.6 mm (14 in), 406.4 mm (16
in), 457.2 mm (18 in), & 508 mm (20 in) belts
2438.4 mm (96 in) to 2514.6 mm (99 in) gauge
setting - compatible up to 762 mm (30 in) belts
2540 mm (100 in) to 4064 mm (160 in) gauge
setting - compatible with all belts
1. General
1-56 Rubber Track Tractor
79036614D
