1.4 Lubricant viscosities and refill capacities
1.4.1 Lubricant viscosities for ambient temperatures
Proper oil viscosity grade is determined by the minimum outside temperature while the machine is started
and while operated.
To determine the proper oil viscosity grade, refer to the minimum column in the following table.
This information reflects the coldest ambient temperature condition for starting and for operating a cold
machine.
Refer to the maximum column in the table to select the oil viscosity grade for operating the machine at the
highest temperature anticipated.
Use the highest oil viscosity allowed for ambient temperature when starting the machine.
Machines operated continuously, should use oils having higher oil viscosity in final drives and in
differentials.
Oils with higher oil viscosity will maintain the highest possible oil film thickness.
Consult a dealer if additional information is needed.
1.4.2 Lubricant viscosities
Compartme
nt or system
Oil type and
classification
Oil
viscosities
Celsius Fahrenheit
Engine
crankcase
AP168,
AP168-4
CJ-4 or ACEA
E9
AGCO Parts
Premium
Extra Engine
Oil
Minimum Maximum Minimum Maximum
SAE 15W40 -20 40 -4 104
Hydraulic
system
AGCO®Perma
tran® 821XL
SAE 10W30 -25 40 -13 104
Transmission
and axles
AGCO®Perma
tran® 821XL
SAE 10W30 -25 40 -13 104
1.4.3 Fill capacities
Approximate fill capacities
Engine coolant 66 L (18.5 gal)
Fuel (w/after-treatment system) 1514 L (400 gal)
Implement/ steering hydraulic circuit 121 L (32 gal)
Transmission and axles 170 L (45 gal)
Fuel (LRC only) 1514 L (400 gal)
Diesel exhaust fluid (DEF) 198 L (52.4 gal)
Engine oil 59 L (15.6 gal)
A/C refrigerant (R - 134a) 1.85 kg (4.07 lb)
Windshield washer fluid 5 L (1.32 gal)
Lubrication (articulation and drivelines) 1 kg (2.2 lb)
