Challenger MT945E - Engine Specifications - MT900 E

1.6 Engine specifications - MT900E
MT955E MT965E MT975E
AP168-4, aftertreatment system, wastegate turbo, air to air intercooled, 12 cylinders, twin series
turbo chargers
365 kW (490 hp) 403 kW (540 hp) 440 kW (590 hp)
standard maximum power
394 kW (529 hp) 435 kW (583 hp) 475 kW (637 hp)
torque at rated power
1660 Nm (1226 lbf ft) 1830 Nm (1351 lbf ft) 2000 Nm (1476 lbf ft)
maximum torque
2360 Nm (1741 lbf ft) 2600 Nm (1918 lbf ft) 2840 Nm (2096 lbf ft)
high idle
2200 rpm in gears 1-15 forward,
neutral, reverse, park; 2300 rpm
in 16th gear forward
2200 rpm in gears 1-15 forward,
neutral, reverse, park; 2300 rpm
in 16th gear forward
2200 rpm in gears 1-15 forward,
neutral, reverse, park; 2300 rpm
in 16th gear forward
governed speed at rated power
2100 rpm 2100 rpm 2100 rpm
low idle
1000 rpm 1000 rpm 1000 rpm
electrical system
12 V 12 V 12 V
maximum altitude at full power
2000 m (6560 ft) 2000 m (6560 ft) 2000 m (6560 ft)
bore and stroke
111 mm x 145 mm (4.37 in x 5.71
in)
111 mm x 145 mm (4.37 in x 5.71
in)
111 mm x 145 mm (4.37 in x 5.71
in)
displacement
1025 cu in (16.8 L) 1025 cu in (16.8 L) 1025 cu in (16.8 L)
MT945E MT955E MT965E MT975E
AP168, wastegate turbo, air to air intercooled, 12 cylinders, twin series turbo chargers
336 kW (450 hp) 365kW (489 hp) 403 kW (540 hp) 440 kW (590 hp)
standard maximum power
363 kW (487 hp) 394 kW (528 hp) 435 kW (583 hp) 475 kW (637 hp)
torque at rated power
1526 Nm (1125 lbf ft) 1658 Nm (1223 lbf ft) 1830 Nm (1351 lbf ft) 2001 Nm (1476 lbf ft)
maximum torque
2167 Nm (1598 lbf ft) 2360 Nm (1740 lbf ft) 2600 Nm (1918 lbf ft) 2842 Nm (2096 lbf ft)
high idle
GUID-90ECC858-6BFC-4E2E-A297-F662713D8A85 [V2]
1. General
Articulated Tractor 1-23
79036231D
