Machine specifications MT900E
Hydraulic System Implement hydraulic system has the following
characteristics:
•
Closed center
• Load sensing
• Pressure and flow compensating pump
Hydraulic pump for implement hydraulic system
• Type - variable displacement axial piston pump
• Maximum flow - 220 liter/min (58 gal/min) and
322 liter/min (85 gal/min)
• Maximum pressure - 20 000 kPa (2900 psi)
Steering system
Machine is equipped with an articulated steering
system. The machine pivots in the center to control
the direction of travel.
Steering system consists of the following
components:
• Two steering cylinders
• Steering/priority valve
• Steering unit
3-point linkage
3-point linkage is electronically controlled. 3-point
linkage will receive category III, category IVN, and
category IV implements.
Lift Capacity for non-steerable 3-point linkage. All
models
• Category III and IVN
8845 kg (19 500 lb)
• Category IV
8845 kg (19 500 lb)
Power Take Off
Machine is equipped with an optional electronically
modulated 1000 RPM power take-off (PTO). This
PTO shaft is a 44.5 mm (1.75 in) 20 tooth spline and
the PTO shaft is a fixed shaft.
Drawbar - CAT IV, (optional), CAT V (standard)
Standard drawbar can be permitted to swing or can
be in a fixed position.
DEF tank Tank sized for one DEF fill for every three fuel fills
based on standard fuel capacity. Actual DEF fill will
vary with engine load. Tank fill capacity 198 L (52.4
gal).
Drivelines Transmission: 9C size, permanently lubricated U-
joint
Front axle: 9C size, permanently lubricated U-joint,
and slip joint
1. General
Articulated Tractor 1-31
79036231D
