Chamberlain ELITE Series Installation Manual

11
Chart Installation
Refer to the illustration to determine the measurements and location of the concrete pad.
Dimension (A) thru (E) are from the center of one pivot point to the center of another pivot point.
Caution: If the gate is longer than 18 feet (5.5 m), follow CHART A: A-2.
Suggestion: The dimensions between the gate and the concrete pad is always 10 inches (25.4 cm) less than the dimension D.
Example: D = 42" (106.7 cm), if the dimensions between the gate and the concrete pad is 32" (81.3 cm).
Chart A
A B C D E DISTANCE
1
46"
(116.8
cm)
35.5"
(90.2 cm)
29.5"
(74.9
cm)
35"
(90.2 cm)
11"
(27.9
cm)
45"
(114.3
cm)
2
46.8"
(118.8
cm)
35.5"
(90.2 cm)
33.5"
(85.1
cm)
42"
(106.7
cm)
11"
(27.9
cm)
37"
(94 cm)
3
46.8"
(118.8
cm)
37"
(94 cm)
31.5"
(80 cm)
40"
(101.6
cm)
11"
(27.9
cm)
41"
(104.1
cm)
4
47.3"
(120 cm)
37.3"
(94.6 cm)
30"
(76.2
cm)
37"
(94 cm)
11"
(27.9
cm)
45"
(114.3
cm)
5
47"
(119.4
cm)
35"
(90.2 cm)
29.5"
(74.9
cm)
32"
(81.3 cm)
11"
(27.9
cm)
45"
(114.3
cm)
6
42.5"
(108 cm)
33"
(116.8
cm)
26.5"
(67.3
cm)
28.5"
(72.4 cm)
11"
(27.9
cm)
41"
(104.1
cm)
Chart B
A B C D E DISTANCE
1
34.5"
(87.6 cm)
34.8"
(88.3
cm)
29.5"
(74.9
cm)
35"
(90.2 cm)
14"
(35.6
cm)
43"
(109.2 cm)
2
44"
(111.8
cm)
36.5"
(92.7
cm)
32.5"
(82.6
cm)
42"
(106.7
cm)
14"
(35.6
cm)
32"
(81.3 cm)
3
44"
(111.8
cm)
37"
(94 cm)
30.5"
(77.5
cm)
40"
(101.6
cm)
14"
(35.6
cm)
40"
(101.6 cm)
4
45"
(114.3
cm)
37"
(94 cm)
30.5"
(77.5
cm)
37"
(94 cm)
14"
(35.6
cm)
43"
(109.2 cm)
5
44.8"
(113.7
cm)
35.8"
(90.8
cm)
29.5"
(74.9
cm)
32"
(81.3 cm)
14"
(35.6
cm)
44"
(111.8 cm)
6
41"
(104.1
cm)
39"
(99.1
cm)
27.5"
(69.9
cm)
28.5"
(72.4 cm)
14"
(35.6
cm)
41"
(104.1 cm)
INSTALLATION

Chamberlain ELITE Series Specifications

General

Battery Backup	Yes
Motor Type	DC
Power Supply	120V AC
Remote Control	Yes
Max Gate Length	20 feet
Smart Home Compatibility	Yes (MyQ compatible)
Maximum Gate Width	20 feet
