Chamberlain ELITE Series Installation Manual

9
Types of Installations
Standard Installation
The illustration is an example of a standard installation.
Compact Installation
The illustration is an example of a compact installation. If the operator arm will hit an obstruction when the gate is in the open position, refer to
LiftMaster.com for compact installation instructions. Entrapment protection devices must be employed in this area.
INSTALLATION

Chamberlain ELITE Series Specifications

General

Battery Backup	Yes
Motor Type	DC
Power Supply	120V AC
Remote Control	Yes
Max Gate Length	20 feet
Smart Home Compatibility	Yes (MyQ compatible)
Maximum Gate Width	20 feet
