Solar usage guide
Typical System Standby Battery Current Consumption (mA)
System voltage 24V
Main board with no radios programmed 2.7 mA
One or more LiftMaster
®
remote controls programmed +1 mA
myQ
®
device or wireless dual gate programmed +2.4 mA
Expansion board +11.1 mA
Per loop detector LOOPDETLM (up to 3 loop detectors can be plugged in to the expansion board) +3.8 mA
Add up current draw by feature and accessory to determine total current draw
NOTE: The use of photoelectric sensor heaters (models LMRRUL and LMTBUL) is NOT recommended in solar applications.
SOLAR GATE CYCLES PER DAY (SINGLE GATE)
BATTERY CURRENT
DRAW (mA)
ZONE 1 ZONE 2 ZONE 3
7AH batteries 33AH batteries 7AH batteries 33AH batteries 7AH batteries 33AH batteries
10W SOLAR PANEL (Must use
24V solar panel)
5 81 87 47 51 18 19
15 68 74 36 39
20 61 68 30 34
40 37 43 13
60 16 21
20W SOLAR PANEL (Two 10W
12V panels in series)
5 100 100 100 100 42 50
15 100 100 92 100 31 38
20 100 100 85 100 25 33
50 100 100 47 63
100 46 70
40W SOLAR PANEL (Two 20W
12V panels in series)
5 100 100 100 100 83 100
15 100 100 100 100 70 100
20 100 100 100 100 63 97
100 100 100 65 100
200 42 100 11
60W SOLAR PANEL
5 263 300 159 286 66 120
15 252 300 149 275 57 111
20 246 300 143 269 53 106
100 160 300 67 181 35
250 24 187 39
SOLAR GATE CYCLES PER DAY (DUAL GATE)
BATTERY CURRENT
DRAW (mA)
ZONE 1 ZONE 2 ZONE 3
7AH batteries 33AH batteries 7AH batteries 33AH batteries 7AH batteries 33AH batteries
10W SOLAR PANEL (Must use
24V solar panel)
5 35 37 20 22
15 29 32 15 17
20 26 29 13 14
40 16 18
60
20W SOLAR PANEL (Two 10W
12V panels in series)
5 76 89 45 53 18 21
15 69 82 39 47 13 16
20 66 79 36 44 11 14
50 48 59 20 27
100 20 30
40W SOLAR PANEL (Two 20W
12V panels in series)
5 100 100 86 100 35 51
15 100 100 79 100 30 45
20 100 100 76 100 27 42
100 77 100 28 58
200 18 63
60W SOLAR PANEL
5 113 203 68 123 28 52
15 108 197 64 118 25 48
20 106 195 62 115 23 45
100 69 153 29 78 15
200 10 80 17
All numbers are estimates. Actual results may vary.
