Carton Inventory
NOT SHOWN: Documentation packet and hardware bag
Hardware Inventory
NOTE: Hardware quantities shown below are for LA412DC. Quantities are doubled for LA412DCS.
Flat Washer 3/8" (3)
Hex Nut 3/8"-16 (3)
Lock Washer 3/8" (3)
Hex Bolt 5/16"-18 x 1-1/2" (1)
Hex Bolt 3/8"-16 x 1-1/2" (1)
Hex Nut 5/16"-18 (1)
Hairpin Clip (2)
Flat Washer 5/16" (1)
Lock Washer 5/16" (1)
Pin (2)
Keylock Cap
Key (2)
Carriage Bolt 3/8" x 5-15/16" (2)
Optional Accessories
Push-to-Open Bracket (Model 50-19503)
If your application requires the gate to be pushed open, a push-to-open
bracket is required, see Accessories.
Expansion Board (Model K1D8387-1CC)
Large Metal Control Box for Solar Applications
(Model XLSOLARCONTUL)
Required for solar installations (batteries not included). Requires two
33AH batteries, battery tray, and solar battery harness, see Accessories.
