Chamberlain LA400PKGUL - Wiring Diagram

48
Standard Control Box
To protect against fire and electrocution:
l DISCONNECT power (AC or solar and battery) BEFORE installing
or servicing operator.
For continued protection against fire:
l Replace ONLY with fuse of same type and rating.
WIRING DIAGRAM
