47
STANDARD CONTROL BOX
ITEM PART NUMBER DESCRIPTION
1 K74-39307-2 Standard Plastic Control Box Only
2 K94-36408-2 Reset Switch with Product ID
3 K94-36411 Piezo Alarm
4 K75-36635 Control Board Bracket
5 K1D8388-1CC Control Board
6 K76-36296-1 Outlet
7 APOW3 Transformer
8 K74-30762 Batteries (2)
NOT SHOWN
K94-36274-1 7AH Battery Harness
K77-36541 Antenna
LA400CONTUL Standard Plastic Control Box with
Control Board
K74-30941 ATC Fuse Kit Includes 20 Amp (1), 15
Amp (2)
GATE OPERATOR ARM
ITEM PART NUMBER DESCRIPTION
1 LA400DC Primary Arm
2 41ASWG-442SA Release Lever
3 41ASWG-438SA Motor with Limit Switch Harness
4 41ASWG-0014SA Rear Connector5
5 41ASWG-489 Cable 24 V with Connector
NOT SHOWN
041ASWG-0119 Release Key
K77-19130 Hardware Bag Complete with:
Gate bracket, post bracket, pull-to-open
bracket and hardware
REPAIR PARTS
