Solar usage guide
Typical System Standby Battery Current Consumption (mA)
System voltage 24V
Main board with no radios programmed 2.7 mA
One or more LiftMaster
®
remote controls programmed +1 mA
myQ
®
device or wireless dual gate programmed +2.4 mA
Expansion board +11.1 mA
Per loop detector LOOPDETLM (up to 3 loop detectors can be plugged in to the expansion board) +3.8 mA
Add up current draw by feature and accessory to determine total current draw
NOTE: The use of photoelectric sensor heaters (models LMRRUL and LMTBUL) is NOT recommended in solar applications.
SOLAR GATE CYCLES PER DAY (SINGLE GATE)
BATTERY CURRENT
DRAW (mA)
ZONE 1 ZONE 2 ZONE 3
7AH batteries 33AH batteries 7AH batteries 33AH batteries 7AH batteries 33AH batteries
10W SOLAR PANEL (Must use
24V solar panel)
5 52 56 30 33 11 12
15 43 47 23 25
20 39 43 19 21
40 24 27
60 10 13
20W SOLAR PANEL (Two 10W
12V panels in series)
5 113 132 67 79 27 32
15 103 122 59 70 20 24
20 98 117 54 65 16 21
50 71 88 30 40
100 29 45
40W SOLAR PANEL (Two 20W
12V panels in series)
5 212 299 128 181 53 75
15 201 288 118 170 44 66
20 196 282 113 165 40 62
100 114 194 41 86
200 27 93
60W SOLAR PANEL (Must use
24V solar panel)
5 263 300 159 286 66 120
15 252 300 149 275 57 111
20 246 300 143 269 53 106
100 160 300 67 181 35
250 24 187 39
SOLAR GATE CYCLES PER DAY (DUAL GATE)
BATTERY CURRENT
DRAW (mA)
ZONE 1 ZONE 2 ZONE 3
7AH batteries 33AH batteries 7AH batteries 33AH batteries 7AH batteries 33AH batteries
10W SOLAR PANEL (Must use
24V solar panel)
5 22 24 13 14
15 19 20 11
20 17 19
40 10 12
60
20W SOLAR PANEL (Two 10W
12V panels in series)
5 48 57 29 34 12 14
15 44 52 25 30 10
20 42 50 23 28
50 30 38 13 17
100 13 19
40W SOLAR PANEL (Two
20W 12V panels in
series)
5 91 129 55 78 23 32
15 86 124 51 73 19 29
20 84 121 49 71 40 27
100 49 83 18 37
200 11 40
60W SOLAR PANEL (Must use
24V solar panel)
5 113 203 68 123 28 52
15 108 197 64 118 25 48
20 106 197 62 115 23 45
100 69 153 29 78 15
250 10 80 17
All numbers are estimates. Actual results may vary.
