Chamberlain LiftMaster Security+ 3800E - Installation Parts; Repair Parts

31
12
NOTICE
1
13
14
15
LOCK
LIGHT
3
4
2
5
6
7
8
9
10
11
Installation Parts
REPAIR PARTS
KEY PART
NO. NO. DESCRIPTION
1 398LM Smart Control Panel™
2 373P 3-Button remote control
3 10A19 3V2016 lithium battery: led and opener
4 10A33 3V2450 lithium battery: proximity switch
5 29C151 Remote control visor clip
6 41A4582 Emergency release rope & handle
assembly
7 41B4494-1 2-Conductor bell wire - white & white/red
8 41A6104 Cable tension monitor
9 41C0902 Mounting bracket
10 41A5034 Safety sensor kit (receiving and
sending eyes) with 3' (.9 m)
2-conductor bell wire attached
KEY PART
NO. NO. DESCRIPTION
11 41A6388 Collar with set screws (2)
12 41A6102 Power door lock
13 41A5266-1 Safety sensor brackets (2)
14 380LM Remote Light (Opener Light)
15 41D96-1 Light lens for light
NOT SHOWN
101D173 Push bar for door control
41A6288 Hardware bag for light
41A6298 Installation hardware bag
(includes hardware listed on page 5)
114A3368 Owner’s manual
