27
Adjustments
STEP1 Program the Travel
Withouta properly installed safetyreversal system,persons (particularly small children) could be
SERIOUSLY INJURED or KILLED by a closing garage door.
l Incorrectadjustment ofgarage door travel limits will interfere with proper operation of safety
reversal system.
l After ANY adjustments are made, the safety reversal system MUST be tested. Door MUST reverse
on contactwith 1-1/2" (3.8 cm) high object(or 2x4 laid flat) on floor.
While programming,the UP and DOWN buttons can be used to move the door as needed.
1. Pressand hold the AdjustmentButton until the UP Button begins to flash.
2. Pressand hold the UP Button until the door is in the desired UP position.
3. Once the door is in the desired UP position press and release the Adjustment Button. The
garage door opener lights will flash twice and the DOWN Button will begin to flash.
4. Pressand hold the DOWNbutton until the door is in the desired DOWNposition.
5. Once the door is in the desired DOWNposition press and release the Adjustment Button. The
garage door opener lights will flash twice and the UP Button will begin to flash.
6. Pressand release the UP Button.When the door travels to the programmed UP position,the
DOWN Button will begin to flash.
7. Pressand release the DOWNButton.The door will travel to the programmed DOWNposition.
Programming is complete.
* Ifthe garage door opener lights are flashing 5 timesduring the steps for Program the Travel,the
programming has timed out. Ifthe garage door opener lights are flashing 10 times during the stepsfor
Program the Travel, the safety reversing sensors are misaligned or obstructed (refer to page 28). When
the sensors are aligned and unobstructed,cycle the door through a complete up and down cycle using
the remote control or the UP and DOWNbuttons. Programming is complete.If you are unable to operate
the door up and down,repeat the steps for Programming the Travel.
UP Button
Adjustment
Button
DOWN Button
PROGRAMMING BUTTONS
