205-04-5 Driving Axle 205-04-5
INSTRUCTION AND OPERATION (Continued)
BENNI MINI
Automobile hoisting
Warning: It is forbidden to use the universal
joint or the driving axle as the jacking
position.
Automobile dragging
Caution: It is forbidden to tie the towing line
on the driving axle.
The protection and rust prevention of the vehicle
bottom
Note: When the protection and rust prevention of the
vehicle bottom are performed, the dust shield should be
covered.
The dirt on the dust shield can lead to the premature
aging of the material, and the foreign matter on the
semi-axle can cause the semi-axle to lose balance.
DIAGNO
SIS AND TESTING
Driving Axle
Table of failure phenomenon
Note: Before check the wear, please reinstall the
driving axle.
1. Visually inspect the dust shield whether it is torn or
has cracks.
DIAGNOSIS AND TESTING
2. Whether the dust shield or the dust clip has
problem can be judged by visually inspect that the front
axle transmission semi-axle under the vehicle bottom
has the oil penetration sign.
3. Check whether the casing of the connecting head
housing has oil dripping.
4. Make sure that the self-locking nuts of the
auxiliary vehicle frame has been installed.
Phenomena
Possible faults
Measures
• Sounds of breaking, knocking or
friction during running
• Insufficient lubrication or pollution
of the universal joint of the driving
axle
• Inspect, clean and replace the grease
if nesssery.
• The driving axle contacting with
other components
• Inspect and repair if nesssery
• The wear or damage of the wheel
bearing, the braking components,
the suspension components or the
steering components
• Inspect and repair if nesssery
• Vibration during high speed driving • The wheels losing balance. • Balancing the wheels
• Radial run-out of the front wheels
• Disassembling and installation
instructions of the driving axle
• Incorrect installation of the driving
axle
•
• Fluttering during acceleration
• Inappropriate assembling height
cause a larger angle of the
three-ball-pin type universal joint
• Check the vehicle height of the
vehicle and the height of the shock
absorbing spring
• The driving axle is excessively
worn or damaged
• Check and replace if necessary
