NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
PARTS LIST
Key Qty Description
1 1 FIREBOX
2 1 LID
3 1 LOGO PLATE
4 1 VALVE/HOSE/REGULATOR ASSEMBLY
5 1 CONTROL PANEL
6 1 BURNER
7 1 ELECTRODE/COLLECTOR
8 2 SIDE SHELF
9 2 MOUNTING BRACKET, F/ SIDE SHELF, (LF/RB)
10 2 MOUNTING BRACKET, F/ SIDE SHELF, (LB/RF)
11 1 CART LEG, UPPER LEFT
12 2 WHEEL
13 1 AXLE ROD
14 1
SIDE BRACE
15 1 CART LEG, UPPER RIGHT
16 1 MATCH HOLDER
17 1 RIGHT BACK LEG, STRAIGHT
18 1 LEFT BACK LEG, STRAIGHT
19 1 RIGHT FRONT LEG, CURVED
20 2 EXTENDER
21 1 LEFT FRONT LEG, CURVED
22 2 SUPPORT BRACKET
23 2 BACK BRACE
24 1 FRONT PANEL
25 1 HANDLE
26 1 HEAT TENT
27 1 COOKING GRATE
28 2 TANK EXCLUSION WIRE
29 1 HEAT SHIELD
30 2 KNOB
31 1 IGNITOR
32 2 LOWER HINGE
33 2 UPPER HINGE
34 1 TANK RETAINER
35 1 GREASE CUP
36 1 GREASE CUP CLIP
NOT Pictured
… 1 HARDWARE PACK
… 1
ASSY INSTRUCTION, ENGLISH, FRENCH,
SPANISH
