PAGE 11
TOP FASCIA PANEL
5
6
Remove / replace TOP FASCIA PANEL.
NOTE: Route the wires through the holes as shown while replacing TOP FASCIA PANEL.
Remove / replace TEMPERATURE PROBE.
TEMPERATURE PROBE
1ST
2ND
Care should be taken when removing the wire tie from the
Temperature Probe and Heating Element wire to prevent
damage.
