PAGE 17
9
10
Remove / replace TEMPERATURE PROBE.
Remove / replace HEATING ELEMENT ASSEMBLY and FIREBOX.
TEMPERATURE PROBE
FIREBOX
HEATING ELEMENT
ASSEMBLY
1ST
Care should be taken when removing the wire tie from the
Temperature Probe and Heating Element wire to prevent
damage.
