PAGE 15
TOP FASCIA PANEL
5
6
Remove / replace TOP FASCIA PANEL.
NOTE: Route the wires through the holes as shown while replacing TOP FASCIA PANEL.
Remove / replace CONTROL PANEL ASSEMBLY.
CONTROL PANEL ASSEMBLY
1ST
1ST
2ND
2ND
