PAGE 20
5
6
Loosen / Tighten the screw assemblies to remove / secure the wires.
Pull out / Route the ground wire as shown.
Remove / Secure the NUT for power cord to remove / replace POWER CORD.
Loosen / Tighten the screws
GROUND WIRE (Green)
NUT
Black Wire
Bottom White Wire
