Char-Broil EDGE - Top Fascia, Temperature Probe, and Control Panel Service; Grease Pan Removal and Replacement; Grates and Baffles Removal

PAGE 5
1
2
Remove / replace GREASE PAN.
Remove / replace COOKING GRATE, WARMING PLATE and GREASE BAFFLE.
Disconnect / connect the wires on CONTROLLER and POWER BOX.
Remove / replace TOP FASCIA PANEL , TEMPERATURE PROBE and CONTROL PANEL
GREASE PAN
WARMING PLATE
COOKING GRATE
GREASE BAFFLE
!
CAUTION
Failure to install grease pan will cause hot grease to drip from
bottom of grill with risk of fire or property damage.
!
POWER BOX
CONTROLLER
1ST
2ND
