Char-Broil EDGE - Heating Element and Reflector Assembly Service; Grease Pan Removal; Grates and Baffles Removal

PAGE 9
1
2
Remove / replace GREASE PAN.
Remove / replace COOKING GRATE, WARMING PLATE and GREASE BAFFLE.
Remove / replace HEATING ELEMENT and REFLECTOR PLATE ASSEMBLY
GREASE PAN
WARMING PLATE
COOKING GRATE
GREASE BAFFLE
!
CAUTION
Failure to install grease pan will cause hot grease to drip from
bottom of grill with risk of fire or property damage.
!
