CHART Trifecta XPro Series - Recommended Spare Parts

46
Preventive Maintenance Product Manual - Trifecta
®
XPro Series
Recommended Spare Parts
www.chartparts.com.
Control Box
Item Description 1 Item Description 2 Chart PN
FUSE FU101 MDA-10 (10 AMP MAIN PANEL) FUSE MDL-1 1/2 AMP SLOW 250V 4614489
FUSE FU-108 AGC-2/10 (2/10TH AMP TRANSMITTER POWER) FUSE BUSSMANN #AGC-2/10-R 12942978
FUSE FU202 MDL-1 (1 AMP PLC POWER) FUSE BUSSMANN #MDL-1 12942943
FUSE FU203 MDL-2 (2 AMP PB VALVE/LIGHT SIDE 1) FUSE BUSSMAN #MDL-2-R 11832398
FUSE FU212 MDL-4 (4 AMP VENT ATM. VALVE/LIGHT) FUSE BUSSMANN #MDL-4-R 12942935
SWITCH MON/OFF/RUN KIT SWITCH TRIFECTA 20686433
LIGHT BULB-LED BULB LED GE GREEN 12942919
TEMPERATURE CONTROLLER-RED LION - PXU100BO TEMP CONTROLLER RED LION 21323109
THERMOCOUPLE TYPE T PROBE THERMOCOUPLE TYPE T 60” LEADS 14271813
PLC MITSUBISHI CONTROLLER AUTOMATION ALD-2YMR-D 11877019
EEPROM Chips
Item Description 1 Item Description 2 Chart PN
EEPROM (UNPROGRAMMED-REQUIRES EEPROM/SERVICE
SPECIFIC)
IC EPROM FOR MITSUBISHI 13090017
EEPROM (X-15 500 psi LIN ONLY) EEPROM TRIFECTA 15X N2 500 PSI 21240345
EEPROM (X-15 500 psi LOX ONLY) EEPROM TRIFECTA 15X O2 500 PSI 21240350
EEPROM (X-15 600 psi LIN ONLY) EEPROM TRIFECTA 15X N2 600 PSI 21240355
Safety Tree
Item Description 1 Item Description 2 Chart PN
SAFETY RELIEF VALVE-CYLINDER (BRS ½”MPT 500 PSI) RV BRS 1/2MPT 500PSI W/O DRAIN 20894583
SAFETY RELIEF VALVE-CYLINDER (BRS ½”MPT 600 PSI)* RV BRS 1/2MPT 600PSI 20547372
RUPTURE DISC-CYLINDER (RPD ASSY. INLINE 1/2”MPT 700 PSI) RPD ASSY INLINE 1/2MPT 700PSI 11526622
RUPTURE DISC-CYLINDER (RPD INLINE 1/2”MPT 800 PSI)* RPD ASSY INLINE 1/2MPT 800PSI 20547371
PRESSURE GAUGE (0-600 PSI) PG 2"DIAL 0/600PSI/BAR/KPA 20827654
PRESSURE GAUGE (0-800 PSI) PG 2"DIAL 0-800 PSI/BAR 21311482
VALVE BALL DIV SS 1/2NPT VALVE BALL DIV SS 1/2NPT 11773885
Regulators/Check Valves/Globe Valves/Ball Valves
Item Description 1 Item Description 2 Chart PN
STRAINER-INLET STRAINER .500ODT BRS BODY 13660471
STRAINER-INLET REPLACEMENT ELEMENT STRAINER ELEMENT KIT SWGLK 440 13729343
CHECK VALVE GENERANT (1 PSI ) ½”FPT X ½”FPT VALVE CHECK BRS 1/2FPTX1/2FPT 13620233
PB INLET/MAUNAL MUFFLER VALVE - REGO T9454 VALVE BRS SH 1/2FPTX1/2FPT 10502848
USE (VALVE GLOVE BRS ½”) - REGO BB9404T VALVE GLOBE BRS 1/2NPT SCRD 20915798
RV BRS 1/4MPT GENERENT CRV-250B-K-720 RV BRS 1/4MPT 720 PSI 21191971
MUFFLER ASSY SS 5/8" 45D FL MUFFLER ASSY SS 5/8" 45D FL 13060248
MUFFLER OXY 7/8” - 14 UNF MUFFLER 9710399
MUFFLER OXY TRIFECTA XPRO SERIES MUFFLER OXY TRIFECTA XPro Series 13744164
4-WAY INSTRUMENT ISOLATION VALVE 1/8 FPT SWAGELOK 20683719
PB RETURN/VENT ISOLATION VALVE 1/2 FPT WORCESTER SHORT STEM 13088865
BOTTOM WITHDRAWAL ISOLATION VALVE 1/2 FPT WORCESTER EXT STEM 20897965
