Product Manual - Trifecta
®
XPro Series
General
XPro Series high-pressure gas supply system.
Chart works closely with our customers to ensure the total
highest performance at the lowest operating cost - all while
management.
Typical Layout
There are three main components to the "Trifecta" system:
• Medium Pressure Bulk Tank (Minimum 175 psig)
• Vaporizer(s)
• Trifecta XPro Series Skid
The Trifecta XPro Series has been designed for ease of
installation and operation. An ideal install has the Trifecta
XPro Series skid close to the liquid use valve on the bulk
vaporizer facing the sun ("heat of the day").
A typical layout is shown here:
Flow Capacity
The Trifecta XPro Series system is designed to supply high
to maintain supply pressure at or above the required pressure
setting. The unique design has self-contained diagnostics that
the Trifecta.
The XPro Series can supply liquid nitrogen and liquid argon
in maximum allowable working pressures from 500 to 600
psi. It can supply liquid oxygen in maximum allowable
working pressures of 500 psi.
Service MAWP*
(psig)
MAOP*
(psig)
LIN
500 450
600 550
LAR
500 450
600 550
LOX 500 450
*MAWP = Maximum Allowable Working Pressure
MAOP = Maximum Allowable Operating Pressure
The system uses ambient vaporizers to maintain pressure
is dependent on the weather conditions. The best ambient
above the freezing point.
The XPro Series was developed and tested by Chart's New
Minnesota winter conditions for optimal performance in the
For example: the Trifecta X10 is rated to deliver liquid
similar to Minnesota. If the end user can tolerate lower
be set to higher pressures.
Note:
for continuous duties in excess of 8-10
hours per day. Higher duty cycles require
auxiliary pressure build capacity and
properly sized process vaporizers.
