Fuses Usage
F7
Data Link
Connector, Left
(Primary)
F8 Empty
F9 OnStar
F10
Body Control
Module 1/Body
Control Module
Electronics/Keyless
Entry/Power Moding/
Center High
Mounted Stoplamp/
License Plate
Lamps/Left Daytime
Running Lamp/Left
Parking Lamps/
Hatch Release
Relay Control/
Washer Pump Relay
Control/Switch
Indicator Lights
Fuses Usage
F11
Body Control
Module 4/Left
Headlamp
F12 Empty
F13 Empty
F14 Empty
F15
Power Outlet (Inside
Floor Console/Rear
of Floor Console)
F16 Empty
F17 Empty
F18 Empty
Relays Usage
R1
Retained Accessory
Power Relay for
Power Outlets
R2 Empty
R3 Empty
R4 Empty
Diodes Usage
DIODE Empty
