10-42 Vehicle Care
Rear Compartment Fuse
Block
The rear compartment fuse block is
on the left side of the rear
compartment behind a removable
cover. Open the latch to remove the
cover and access the fuse block.
A fuse puller is located in the engine
compartment fuse block.
The vehicle may not have all of the
fuses, relays, and features shown.
Fuses Usage
F1 Empty
F2
Fuel System Control
Module
Fuses Usage
F3
Passive Start/
Passive Entry
Module
F4
Heated Seats
(If Equipped)
To Next Page
