Chevrolet Volt Owner Manual - 2012
Vehicle Care 10-43
Fuses Usage
F5
Driver Door
Switches (Outside
Rearview Mirror/
Charge Port Door
Release/Refuel
Request/Driver
Window Switch)
F6
Fuel (Diurnal Valve
and Evap. Leak
Check Module)
F7
Accessory Power
Module Cooling Fan
F8
Amplifier
(If Equipped)
F9 Empty
F10
Regulated Voltage
Control/Ultrasonic
Front and Rear
Parking Assist
(If Equipped)
Fuses Usage
F11 Horn
F12
Rear Power
Windows
F13
Electric Parking
Brake
F14
Rear Defog
(Upper Grid)
F15 Empty
F16 Hatch Release
F17 Empty
F18 Empty
Relays Usage
R1
Rear Defog
(Upper Grid)
R2 Hatch Release
R3 Empty
R4 Empty
R5 Empty
R6 Empty
R7/R8 Horn
Diodes Usage
DIODE Empty
