Chevrolet Volt Owner Manual - 2012
Vehicle Care 10-41
Fuses Usage
F6
Body Control
Module 5/Retained
Accessory Power
Relay Control/Right
Front Turn Signal
Lamp/Left Rear Stop
and Turn Signal
Lamp/Right Parking
Lamps/Remote
PRNDL
F7
Body Control
Module 6/
Map Lights/
Courtesy Lights/
Back – up Lamp
F8
Body Control
Module 7/Left Front
Turn Signal/Right
Rear Stop and Turn
Signal Lamp/Child
Security Lock Relay
Control
Fuses Usage
F9
Body Control
Module 8/Locks
F10
Data Link
Connector, Right
(Secondary)
F11
Universal Garage
Door Opener
(If Equipped)
F12 Blower Motor
F13 Empty
F14 Empty
F15 Empty
F16 Empty
F17 Empty
F18 Empty
Relays Usage
R1 Empty
R2 Empty
R3 Empty
R4 Child Lockout Relay
Diodes Usage
DIODE Empty
