Chevrolet Sonic 2012 - Page 244

Black plate (36,1)
Chevrolet Sonic Owner Manual - 2012
10-36 Vehicle Care
Number Usage
28
Heated Outside
Rearview Mirror
29 Not Used
30 Heated Front Seat
31
Fuel System
Control Module 1
(1.4L), Not
Used (1.8L)
32 Flex Fuel
33 Washer
34
Fuel Pump
Relay (1.8L)
35 Fuel Pump (1.8L)
36
Engine Control
Module/
Transmission
Control Module
37
Fuel System
Control Module 2
(1.4L), Not
Used (1.8L)
38 Not Used
Number Usage
39 Cooling Fan K5
40 Cooling Fan K4
41 EVP
42
Engine Control
Module
43
Air Conditioning
Compressor Clutch
44
Transmission
Control Module
45
Engine Control
Module 1
46 Coil
47
Engine Control
Module 4
48
Engine Control
Module 3
49
Engine Control
Module 2
50 Injector
51 Powertrain Relay
Number Usage
52 Horn
53
Cooling Fan K3
Relay (1.8L),
Cooling Fan K3
High Current
Relay (1.4L)
54 Start
55 Start Relay
56
Air Conditioning
Compressor Clutch
Relay
57 High‐Beam Relay
58 Front Fog Lamps
59 Left High Beam
60 Right High Beam
61
Cooling Fan K1
Relay
62
Cooling Fan K2
Relay (1.4L)
