Black plate (37,1)
Chevrolet Sonic Owner Manual - 2012
Vehicle Care 10-37
Instrument Panel Fuse
Block
The instrument panel fuse block is
located on the underside of the
driver side instrument panel.
Notice: Spilling liquid on any
electrical component on the
vehicle may damage it. Always
keep the covers on any electrical
component.
Number Usage
1 DLIS
2
Data Link
Connector
3 Airbag
4 Tailgate
5 Spare
6
Body Control
Module
7
Body Control
Module
8
Body Control
Module
9
Body Control
Module
10
Body Control
Module
11
Body Control
Module
