11) Use ESC button to return to View Data menu and/or return to
Live Data menu.
Recording Data
The Record Data function allows recording vehicle modules’
Parameter Identification (PID) data to help diagnose intermittent
vehicle problems. A recording includes 5 frames of live data
before trigger event and several frames after trigger event.
There are two trigger modes used to record data:
A. Manual Trigger - allows user to press ENTER button to start
recording.
B. DTC Trigger - automatically records PID data when a fault that
causes a DTC to set is detected by vehicle.
CAUTION: DO NOT try to drive and operate the scan tool at the
same time! Always have another person operate the scan tool while
driving.
1) To record live data, use UP/DOWN scroll button to select
Record Data from Live Data menu and press ENTER button.
……………….Live Data…………………….
