Chigo CCB-12HR1 - The Specification of Power

R410A50Hz Universal Outdoor Series Technical ManualFloor ceiling
115
GD Chigo Heating & Ventilation Equipment Co., Ltd.
11.The Specification of Power
Model 18kBtu/h 24kBtu/h 36kBtu/h
Indoor power supply V/Ph/Hz 220~240/1/50
Outdoor power supply V/Ph/Hz 220~240/1/50
Connection
wiring
Outdoor Power
Supply
From indoor
unit
Power supply individually for indoor and
outdoor
Power
wiring
mm
2
3×2.5 3×2.5/3×1.0 3×4.0/3×1.0
Signal
wiring
mm
2
5×1.5 RS485 twisted shielded wire pair 2×0.5
Model 36kBtu/h 48kBtu/h 60kBtu/h
Indoor power supply V/Ph/Hz 220~240/1/50
Outdoor power supply V/Ph/Hz 380~415/3/50
Connection wiring
Outdoor Power Supply
Power supply individually for indoor and outdoor
Power wiring mm
2
5×1.5/3×1.0 5×1.5/3×1.0 5×2.5/3×1.0
Signal wiring mm
2
RS485 twisted shielded wire pair 2×0.5
