Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
43
GD Chigo Heating & Ventilation Equipment Co., Ltd.
11. The Specification of Wiring
Model 12kBtu/h 18kBtu/h 24kBtu/h 36kBtu/h
Indoor power supply V/Ph/Hz 220~240/1/50
Outdoor power supply V/Ph/Hz 220~240/1/50
Connection
wiring
Outdoor Power
Supply
From
indoor unit
From
indoor unit
Power supply individually for
indoor and outdoor
Power
wiring
mm
2
3×1.5 3×2.5 3×2.5/3×1.0 3×4.0/3×1.0
Signal
wiring
mm
2
5×1.5 5×1.5
RS485 twisted shielded wire pair
2×0.5
Model 36kBtu/h 48kBtu/h 60kBtu/h
Indoor power supply V/Ph/Hz 220~240/1/50
Outdoor power supply V/Ph/Hz 380~415/3/50
Connection wiring
Outdoor Power Supply Power supply individually for indoor and outdoor
Power
wiring
mm
2
5×1.5/3×1.0 5×1.5/3×1.0 5×2.5/3×1.0
Signal
wiring
mm
2
RS485 twisted shielded wire pair 2×0.5
