R410A50Hz Universal Outdoor Series Technical ManualFloor ceiling
120
GD Chigo Heating & Ventilation Equipment Co., Ltd.
type
Number of circuits
4
4
4
5
5
3
3
Outdoor air
flow(High speed)
m
3
/h 2000 2800 2800 3800 3800 6000 6000
Outdoor noise level
dB(A)
55
53
53
58
58
65
65
Outdo
or unit
Dimension(
W*H*D)
mm
866×304
×535
866×304
×535
866×304
×535
930×370×
700
930×370×
700
1070×40
0×995
1070×40
0×995
Packing(W
*H*D)
mm
920×335
×585
920×335
×585
920×335
×585
990×410×
770
990×410×
770
1145×47
5×1120
1145×47
5×1120
Net/Gross
weight
kg 36/38 41/43 41/43 52/56 52/56 92/100 92/100
Refrigerant
type/quantity
g
R410A/1
100
R410A/1
200
R410A/1
200
R410A/18
00
R410A/18
00
R410A/2
100
R410A/2
100
Throttle part
capillary
capillary
capillary
capillary
capillary
capillary
capillary
Design
pressu
re
MPa 4.0/1.2 4.0/1.2 4.0/1.2 4.0/1.2 4.0/1.2 4.0/1.2 4.0/1.2
Max pressure
MPa
4
4
4
4.5
4.5
4.5
4.5
Conne
ction
wiring
Power
wiring
mm
2
3×1.5 3×2.5 3×2.5
3×2.5/3×1
.0
3×2.5/3×1
.0
3×4.0/3×
1.0
3×4.0/3×
1.0
Signal
wiring
mm
2
5×1.5 5×1.5 5×1.5 RS485 twisted shielded wire pair
Refrig
erant
piping
Liquid
side/Gas
side
mm
φ6.35/φ
12.7
φ6.35/φ
12.7
φ6.35/φ
12.7
Φ9.52/Φ1
5.88
Φ9.52/Φ1
5.88
Φ9.52/Φ
19.05
Φ9.52/Φ
19.05
Max. pipe
length
m 15 25 25 25 25 30 30
Max. high
drop
m 8 15 15 15 15 20 20
Ambient temp
°C
-7
～
50
-7
～
50
-7
～
50
-7
～
50
-7
～
50
-7
～
50
-7
～
50
Stuffing Quantity
20'/40'/
40'HQ
100/200
/208
100/200
/208
100/200
/208
70/140/1
44
70/140/1
44
40/80/8
0
40/80/8
0
Model
COU-36HS
R1
COU-36CS
R1
COU-48HS
R1
COU-48CS
R1
COU-60HS
R1
COU-60CS
R1
Outdoor power supply V/Ph/Hz
380~415/3
/50
380~415/3
/50
380~415/
3/50
380~415/
3/50
380~415/
3/50
380~415/
3/50
Cooling
Capacity
Btu/h
36000
36000
48000
48000
60000
60000
KW
10.5
10.5
14
14
16
16
Input
W
3800
3800
5000
5000
5700
5700
Rated current A 6.9 6.9 8.2 8.2 10 10
Heating
Capacity
Btu/h
39000
52000
60000
KW
11.5
15.2
16
Input
W
3600
5100
5800
Rated current A 6.5 8.4 10.2
Max. input consumption
W
4900
4900
6000
6000
6600
6600
Max. current
A
10.3
10.3
10.5
10.5
11.8
11.8
Compre
ssor
Model
C-SBN303
H8D
C-SBN303
H8D
C-SBN373
H8D
C-SBN373
H8D
C-SBN453
H8D
C-SBN453
H8D
