R410A50Hz Universal Outdoor Series TechnicalManual Outdoor unit
142
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantity
No.
Part Name
Quantity
1 Front top net 1 12.10
Control wire for 4-Ways
valve
1
2
Front panel
1
12.11
Contactor
1
3
Propeller fan
1
13
Right clapboard
1
4
Handle
1
14
Handle
1
5
Left clapboard
1
15.1
Valve holder
1
6
Fan motor
1
15.2
Cut-off valve DN8
1
7
Holder for fan motor
1
15.3
Cut-off valve DN13
1
8
Condenser assy
1
16
Suction pipe
1
9 Cover 1 17
Pre-welding assy for
throttle capillary
1
10
Back connection
1
18
Discharge pipe assy
1
11
4-Ways valve assy
1
19
Compressor
1
11.1
4-Ways valve
1
20
Chassis
1
11.2
Return pipe of compressor
1
21
Separating board
1
11.3
Low pressure valve connecting
pipe
1 22 Maintenance panel 1
12
E-parts assy
1
