Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series TechnicalManual Outdoor unit
150
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantity
No.
Part Name
Quantity
1
Handle
3
14.3
Cut-off valve DN16
1
2
Top net
2 14.4
4-Ways valve connecting
pipe
1
3
Front panel
1 14.5
4-Ways valve connecting
pipe
1
4
Propeller fan
2 14.6
4-Ways valve connecting
pipe
1
5
Column
1 14.7
Control wire for 4-Ways
valve
1
6
Fan motor
2
15
E-parts assy
1
7
Holder for fan motor
1
15.1
Temp sensor
1
8 Motor bracket connecting plate 1 15.2
Electric control board
assy
1
9
Condenser assy
1
15.3
Terminal
1
9.1
Condenser
1
15.4
Terminal
1
9.2
Collector components
1
15.5
Groove clamp 3
1
9.3
Cold out pipe
1
15.6
Groove clamp 9
1
9.4
Condenser inlet tube shockproof
tubule
1 15.7
Exhaust temp sensor
1
9.5
Probe of copper pipe
1 15.8
Electronic control
mounting plate
1
9.6
Distributing capillary assy
1
15.9
Protection cap
1
10
Cover
1
15.10
Fan motor capacitor
2
11
High pressure valve connecting
pipe assy
1 15.11
Contactor
1
11.1
filter
1
16
Rear panel
1
11.2
Refrigeration capillary
1
17
Rear side valve board
1
11.3
High pressure valve connecting
pipe
1 18
Right clapboard
1
11.4
Cut-off valve DN8
1
19
Suction pipe assy
1
12
Valve holder
1
19.1
Suction pipe
1
13
Discharge pipe assy
1
19.2
Low-pressure switch
1
13.1
Discharge pipe
1
20
Machine foot cover
1
13.2
Probe of copper pipe
1
21
Compressor assy
1
13.3
High-pressure switch
1
22
Chassis
1
13.4
Probe of copper pipe
1
23
Vapor-liquid separator
1
14
4-Ways valve assy
1
24
Separating board
1
14.1
4-Ways valve
1
14.2
Process pipe
1
