Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
15
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Indoor air flow(High speed) m
3
/h 1200 1200 1200 1200
Indoor noise level
dB(A)
44
～
48
44
～
48
44
～
48
44
～
48
Indoor
unit
Dimension(W*H
*D)
Body(m
m)
840×230×840 840×230×840 840×230×840 840×230×840
Panel(m
m)
950×50×950 950×50×950 950×40×950 950×40×950
Packing(W*H*D
)
Body(m
m)
920×265×920 920×265×920 920×265×920 920×265×920
Panel(m
m)
1030×105×10
30
1030×105×10
30
1030×100×10
30
1030×100×10
30
Net/Gross
weight
Body(Kg
)
24/29 24/29 24/29 24/29
Panel(Kg
)
5.4/8.0 5.4/8.0 5.4/8.0 5.4/8.0
Max
pressure
MPa 4 4 4 4
Refrigerant type
R410A
R410A
R410A
R410A
Refrigera
nt piping
Liquid side/Gas
side
mm Φ9.52/Φ15.88 Φ9.52/Φ15.88 Φ9.52/Φ15.88 Φ9.52/Φ15.88
Drainage pipe
mm
DN25
DN25
DN25
DN25
Standard controller
Operation temp
°C
16
～
32
16
～
32
16
～
32
16
～
32
Ambient
temp
cooling
°C
18-50
18-50
18-50
18-50
heating
°C
-7
～
24
-7
～
24
-7
～
24
-7
～
24
Application area
m
2
28-50
28-50
28-50
28-50
Stuffing
Quantity(20'/40'/40'HQ)
set 75/155/170 75/155/170 75/155/170 75/155/170
Model CCA-36HR1 CCA-36CR1 CCR-36HR1 CCR-36CR1
Indoor power supply V/Ph/Hz 220~240/1/50 220~240/1/50 220~240/1/50 220~240/1/50
Cooling
Capacity
Btu/h
36000
36000
36000
36000
KW
10.5
10.5
10.5
10.5
Input
W
160
160
160
160
Rated current A 0.8 0.8 0.8 0.8
EER
W/W
2.71
2.71
2.71
2.71
Heating
Capacity
Btu/h
39000
39000
KW
11.5
11.5
Input
W
160
160
Rated current A 0.8 0.8
COP
W/W
3.31
3.31
Indoor
fan motor
Model YDK-75T-6 YDK-75T-6 YDK-75T-6 YDK-75T-6
Input
W
160
160
160
160
Capacitor
μF
4
4
4
4
Speed(Hi/Me/Lo
)
r/min 760/680/580 760/680/580 760/680/580 760/680/580
Indoor
Number of rows
2
2
2
2
