Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
17
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Heating
Capacity
Btu/h
52000
52000
KW
15.2
15.2
Input
W
180
180
Rated current A 0.8 0.8
COP
W/W
2.88
2.88
Indoor
fan motor
Model
YDK-75Q-6P3
-1
YDK-75Q-6P3
-1
YDK-75Q-6P
3-1
YDK-75Q-6P
3-1
Input
W
180
180
180
180
Capacitor
μF
5
5
5
5
Speed(Hi/Me/Lo
)
r/min 850/750/650 850/750/650 850/750/650 850/750/650
Indoor
coil
Number of rows
2
2
2
2
Tube pitch(a) x
row pitch(b)
mm 21×13.37 21×13.37 21×13.37 21×13.37
Fin spacing
mm
1.45
1.45
1.45
1.45
Fin type Hydrophilic Hydrophilic Hydrophilic Hydrophilic
Tube outside
dia. and type
mm
Ф7
Ф7
Φ7
Φ7
inner grooved inner grooved Inner grooved Inner grooved
Coil length x
height x width
mm
2000×252×26.
74
2000×252×26.
74
2000×252×26
74
2000×252×26
74
Number of circuits
12
12
12
12
Indoor air flow(High speed) m
3
/h 1900 1900 1900 1900
Indoor noise level
dB(A)
45
～
52
45
～
52
45
～
52
45
～
52
Indoor
unit
Dimension(W*H
*D)
Body(m
m)
840×285×840 840×285×840 840×285×840 840×285×840
Panel(m
m)
950×50×950 950×50×950 950×40×950 950×40×950
Packing(W*H*D
)
Body(m
m)
920×310×920 920×310×920 920×310×920 920×310×920
Panel(m
m)
1030×105×10
30
1030×105×10
30
1030×100×10
30
1030×100×10
30
Net/Gross
weight
Body(Kg)
28/33.5
28/33.5
28/33.5
28/33.5
Panel(Kg
)
5.4/8.0 5.4/8.0 5.4/8.0 5.4/8.0
Max
pressure
MPa 4.5 4.5 4.5 4.5
Refrigerant type
R410A
R410A
R410A
R410A
Refrigera
nt piping
Liquid side/Gas
side
mm Φ9.52/Φ19.05 Φ9.52/Φ19.05
Φ9.52/Φ19.0
5
Φ9.52/Φ19.0
5
Drainage pipe
mm
DN25
DN25
DN25
DN25
Standard controller
Operation temp
°C
16
～
32
16
～
32
16
～
32
16
～
32
Ambient
temp
cooling
°C
18-50
18-50
18-50
18-50
heating
°C
-7
～
24
-7
～
24
-7
～
24
-7
～
24
Application area
m
2
55~95
55~95
55~95
55~95
Stuffing
Quantity(20'/40'/40'HQ)
set 65/130/150 65/130/150 65/130/150 65/130/150
