R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
19
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Refrigerant type
R410A
R410A
R410A
R410A
Refrigera
nt piping
Liquid side/Gas
side
mm Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05
Drainage pipe
mm
DN25
DN25
DN25
DN25
Standard controller
Operation temp
°C
16
～
32
16
～
32
16
～
32
16
～
32
Ambient
temp
cooling
°C
18-50
18-50
18-50
18-50
heating
°C
-7
～
24
-7
～
24
-7
～
24
-7
～
24
Application area
m
2
60~105
60~105
60~105
60~105
Stuffing
Quantity(20'/40'/40'HQ)
set 65/130/150 65/130/150 65/130/150 65/130/150
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 5m(horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 5m(horizontal)
3. Actual noise level may differ, depending on the room structure, etc. since these noise values are from an
anechoic room.
